آزمایشگاه 5 (AARCH64) – آزمایشگاه زبان مونتاژ 64 بیتی

tar xvf /public/spo600-assembler-lab-examples.tgz

 spo600
 └── examples
     └── hello                     # "hello world" example programs
         ├── assembler
         │   ├── aarch64           # aarch64 gas assembly language version
         │   │   ├── hello.s
         │   │   └── Makefile
         │   ├── Makefile
         │   └── x86_64            # x86_64 assembly language versions
         │       ├── hello-gas.s   # ... gas syntax
         │       ├── hello-nasm.s  # ... nasm syntax
         │       └── Makefile
         └── c                     # Portable C versions
             ├── hello2.c          # ... using write()
             ├── hello3.c          # ... using syscall()
             ├── hello.c           # ... using printf()
             └── Makefile

cd ~/spo600/examples/hello/assembler/aarch64

make

./hello

objdump -d hello.o > hello_disassembled.txt

hello.o:     file format elf64-littleaarch64


Disassembly of section .text:

0000000000000000 <_start>:
   0:   d2800020        mov     x0, #0x1                        // #1
   4:   10000001        adr     x1, 0 <_start>
   8:   d28001c2        mov     x2, #0xe                        // #14
   c:   d2800808        mov     x8, #0x40                       // #64
  10:   d4000001        svc     #0x0
  14:   d2800000        mov     x0, #0x0                        // #0
  18:   d2800ba8        mov     x8, #0x5d                       // #93
  1c:   d4000001        svc     #0x0

.text
.globl _start
_start:

        mov     x0, 1           /* file descriptor: 1 is stdout */
        adr     x1, msg         /* message location (memory address) */
        mov     x2, len         /* message length (bytes) */

        mov     x8, 64          /* write is syscall #64 */
        svc     0               /* invoke syscall */

        mov     x0, 0           /* status -> 0 */
        mov     x8, 93          /* exit is syscall #93 */
        svc     0               /* invoke syscall */

.data
msg:    .ascii      "Hello, world!\n"
len=    . - msg

 .text
 .globl _start
 min = 0                          /* starting value for the loop index; **note that this is a symbol (constant)**, not a variable */
 max = 6                         /* loop exits when the index hits this number (loop condition is i
 _start:
     mov     x19, min
 loop:

     /* ... body of the loop ... do something useful here ... */

     add     x19, x19, 1     /* increment the loop counter */
     cmp     x19, max        /* see if we've hit the max */
     b.ne    loop            /* if not, then continue the loop */

     mov     x0, 0           /* set exit status to 0 */
     mov     x8, 93          /* exit is syscall #93 */
     svc     0               /* invoke syscall */

.text
.globl _start

min = 0                          /* starting value for the loop index */
max = 6                          /* loop exits when the index hits this number */

_start:
    mov     x19, min            /* initialize loop counter */
loop:
    /* Print "Loop" message */
    mov     x0, 1               /* file descriptor: 1 is stdout */
    adr     x1, msg             /* message location (memory address) */
    mov     x2, len             /* message length (bytes) */
    mov     x8, 64              /* write is syscall #64 */
    svc     0                   /* invoke syscall */

    add     x19, x19, 1         /* increment the loop counter */
    cmp     x19, max            /* see if we've hit the max */
    b.ne    loop                /* if not, then continue the loop */

    mov     x0, 0               /* set exit status to 0 */
    mov     x8, 93              /* exit is syscall #93 */
    svc     0                   /* invoke syscall */

.data
msg:    .ascii      "Loop\n"
len=    . - msg

make clean
make
./hello

[kzaw@aarch64-002 aarch64]$ ./hello
Loop
Loop
Loop
Loop
Loop
Loop

add     x20, x19, #48       /* x20 = x19 + 48 (ASCII '0') */

msg:    .ascii      "Loop: #\n"    /* # is a placeholder for the digit */

adr     x21, msg            /* Get address of message */
add     x21, x21, #6        /* Position of the digit character (after "Loop: ") */
strb    w20, [x21]          /* Store the ASCII character at that position */

.text
.globl _start

min = 0                          /* starting value for the loop index */
max = 6                          /* loop exits when the index hits this number */

_start:
    mov     x19, min            /* initialize loop counter */
loop:
    /* Convert loop counter to ASCII character */
    add     x20, x19, #48       /* x20 = x19 + 48 (ASCII '0') */

    /* Store the ASCII digit in the message */
    adr     x21, msg            /* Get address of message */
    add     x21, x21, #6        /* Position of the digit character (after "Loop: ") */
    strb    w20, [x21]          /* Store the ASCII character at that position */

    /* Print message with loop counter */
    mov     x0, 1               /* file descriptor: 1 is stdout */
    adr     x1, msg             /* message location (memory address) */
    mov     x2, len             /* message length (bytes) */
    mov     x8, 64              /* write is syscall #64 */
    svc     0                   /* invoke syscall */

    add     x19, x19, 1         /* increment the loop counter */
    cmp     x19, max            /* see if we've hit the max */
    b.ne    loop                /* if not, then continue the loop */

    mov     x0, 0               /* set exit status to 0 */
    mov     x8, 93              /* exit is syscall #93 */
    svc     0                   /* invoke syscall */

.data
msg:    .ascii      "Loop: #\n"    /* # is a placeholder for the digit */
len=    . - msg

[kzaw@aarch64-002 aarch64]$ ./hello
Loop: 0
Loop: 1
Loop: 2
Loop: 3
Loop: 4
Loop: 5

mov     x22, x19            /* Copy loop counter to x22 */

/* Calculate tens digit: quotient of division by 10 */
mov     x23, #10            /* Set divisor to 10 */
udiv    x20, x22, x23       /* x20 = x22 / 10 (quotient = tens digit) */

/* Calculate ones digit: remainder of division by 10 */
mul     x24, x20, x23       /* x24 = quotient * 10 */
sub     x21, x22, x24       /* x21 = original - (quotient * 10) = remainder */

/* Convert digits to ASCII */
add     x20, x20, #48       /* Convert tens digit to ASCII */
add     x21, x21, #48       /* Convert ones digit to ASCII */

/* Store the ASCII digits in the message */
adr     x24, msg            /* Get address of message */
add     x24, x24, #6        /* Position of the first digit (after "Loop: ") */
strb    w20, [x24]          /* Store the tens digit */
add     x24, x24, #1        /* Move to the position of the second digit */
strb    w21, [x24]          /* Store the ones digit */

.text
.globl _start

min = 0                          /* starting value for the loop index */
max = 33                         /* loop exits when the index hits this number */

_start:
    mov     x19, min            /* initialize loop counter */
loop:
    /* Convert loop counter to two ASCII digits */
    mov     x22, x19            /* Copy loop counter to x22 */

    /* Calculate tens digit: quotient of division by 10 */
    mov     x23, #10            /* Set divisor to 10 */
    udiv    x20, x22, x23       /* x20 = x22 / 10 (quotient = tens digit) */

    /* Calculate ones digit: remainder of division by 10 */
    mul     x24, x20, x23       /* x24 = quotient * 10 */
    sub     x21, x22, x24       /* x21 = original - (quotient * 10) = remainder */

    /* Convert digits to ASCII */
    add     x20, x20, #48       /* Convert tens digit to ASCII */
    add     x21, x21, #48       /* Convert ones digit to ASCII */

    /* Store the ASCII digits in the message */
    adr     x24, msg            /* Get address of message */
    add     x24, x24, #6        /* Position of the first digit (after "Loop: ") */
    strb    w20, [x24]          /* Store the tens digit */
    add     x24, x24, #1        /* Move to the position of the second digit */
    strb    w21, [x24]          /* Store the ones digit */

    /* Print message with loop counter */
    mov     x0, 1               /* file descriptor: 1 is stdout */
    adr     x1, msg             /* message location (memory address) */
    mov     x2, len             /* message length (bytes) */
    mov     x8, 64              /* write is syscall #64 */
    svc     0                   /* invoke syscall */

    add     x19, x19, 1         /* increment the loop counter */
    cmp     x19, max            /* see if we've hit the max */
    b.ne    loop                /* if not, then continue the loop */

    mov     x0, 0               /* set exit status to 0 */
    mov     x8, 93              /* exit is syscall #93 */
    svc     0                   /* invoke syscall */

.data
msg:    .ascii      "Loop: ##\n"   /* ## are placeholders for the two digits */
len=    . - msg

[kzaw@aarch64-002 aarch64]$ ./hello
Loop: 00
Loop: 01
...
Loop: 09
Loop: 10
...
Loop: 32

.data
msg1:   .ascii      "Loop:  #\n"   /* Single-digit format (note: two spaces after colon) */
len1=   . - msg1
msg2:   .ascii      "Loop: ##\n"   /* Double-digit format (note: one space after colon) */
len2=   . - msg2

/* Determine if number is single or double digit */
cmp     x20, #48            /* Compare tens digit to ASCII '0' */
b.ne    double_digit        /* If not '0', it's a double-digit number */

/* Single-digit case (0-9) */
adr     x24, msg1           /* Get address of single-digit message */
strb    w21, [x24, #6]      /* Store ones digit at position after "Loop: " */
mov     x1, x24             /* Set message address for print */
mov     x2, len1            /* Set message length */
b       print_msg           /* Jump to print routine */

double_digit:
    /* Double-digit case (10-32) */
    adr     x24, msg2           /* Get address of double-digit message */
    strb    w20, [x24, #6]      /* Store tens digit */
    strb    w21, [x24, #7]      /* Store ones digit */
    mov     x1, x24             /* Set message address for print */
    mov     x2, len2            /* Set message length */

print_msg:
    /* Print message with loop counter */
    mov     x0, 1               /* file descriptor: 1 is stdout */
    mov     x8, 64              /* write is syscall #64 */
    svc     0                   /* invoke syscall */

.text
.globl _start

min = 0                          /* starting value for the loop index */
max = 33                         /* loop exits when the index hits this number */

_start:
    mov     x19, min            /* initialize loop counter */
loop:
    /* Convert loop counter to two ASCII digits */
    mov     x22, x19            /* Copy loop counter to x22 */

    /* Calculate tens digit: quotient of division by 10 */
    mov     x23, #10            /* Set divisor to 10 */
    udiv    x20, x22, x23       /* x20 = x22 / 10 (quotient = tens digit) */

    /* Calculate ones digit: remainder of division by 10 */
    mul     x24, x20, x23       /* x24 = quotient * 10 */
    sub     x21, x22, x24       /* x21 = original - (quotient * 10) = remainder */

    /* Convert digits to ASCII */
    add     x20, x20, #48       /* Convert tens digit to ASCII */
    add     x21, x21, #48       /* Convert ones digit to ASCII */

    /* Determine if number is single or double digit */
    cmp     x20, #48            /* Compare tens digit to ASCII '0' */
    b.ne    double_digit        /* If not '0', it's a double-digit number */

    /* Single-digit case (0-9) */
    adr     x24, msg1           /* Get address of single-digit message */
    strb    w21, [x24, #7]      /* Store ones digit at position after "Loop:  " */
    mov     x1, x24             /* Set message address for print */
    mov     x2, len1            /* Set message length */
    b       print_msg           /* Jump to print routine */

double_digit:
    /* Double-digit case (10-32) */
    adr     x24, msg2           /* Get address of double-digit message */
    strb    w20, [x24, #6]      /* Store tens digit */
    strb    w21, [x24, #7]      /* Store ones digit */
    mov     x1, x24             /* Set message address for print */
    mov     x2, len2            /* Set message length */

print_msg:
    /* Print message with loop counter */
    mov     x0, 1               /* file descriptor: 1 is stdout */
    mov     x8, 64              /* write is syscall #64 */
    svc     0                   /* invoke syscall */

    add     x19, x19, 1         /* increment the loop counter */
    cmp     x19, max            /* see if we've hit the max */
    b.ne    loop                /* if not, then continue the loop */

    mov     x0, 0               /* set exit status to 0 */
    mov     x8, 93              /* exit is syscall #93 */
    svc     0                   /* invoke syscall */

.data
msg1:   .ascii      "Loop:  #\n"   /* Single-digit format (note: two spaces after colon) */
len1=   . - msg1
msg2:   .ascii      "Loop: ##\n"   /* Double-digit format (note: one space after colon) */
len2=   . - msg2

Loop:  0
Loop:  1
Loop:  2
...
Loop:  9
Loop: 10
Loop: 11
...
Loop: 32

    mov     x23, #16

    cmp     x20, #10            /* Check if high nibble is less than 10 */
    blt     high_digit_decimal
    add     x20, x20, #55       /* For hex A-F */
    b       high_digit_done
high_digit_decimal:
    add     x20, x20, #48       /* For digits 0-9 */
high_digit_done:

.text
.globl _start

min = 0                          /* starting value for the loop index */
max = 33                         /* loop exits when the index hits this number */

_start:
    mov     x19, min            /* initialize loop counter */
loop:
    /* Convert loop counter to two hexadecimal digits */
    mov     x22, x19            /* Copy loop counter to x22 */

    /* Calculate high nibble: quotient of division by 16 */
    mov     x23, #16            /* Set divisor to 16 for hex */
    udiv    x20, x22, x23       /* x20 = x22 / 16 (high nibble) */

    /* Calculate low nibble: remainder of division by 16 */
    mul     x24, x20, x23       /* x24 = high nibble * 16 */
    sub     x21, x22, x24       /* x21 = original - (high nibble * 16) = low nibble */

    /* Convert high nibble to ASCII */
    cmp     x20, #10            /* Check if high nibble is less than 10 */
    blt     high_digit_decimal
    /* For hex A-F: add 55 (10+55=65 -> 'A') */
    add     x20, x20, #55
    b       high_digit_done
high_digit_decimal:
    add     x20, x20, #48       /* For digits 0-9: add 48 ('0') */
high_digit_done:

    /* Convert low nibble to ASCII */
    cmp     x21, #10            /* Check if low nibble is less than 10 */
    blt     low_digit_decimal
    /* For hex A-F */
    add     x21, x21, #55
    b       low_digit_done
low_digit_decimal:
    add     x21, x21, #48       /* For digits 0-9 */
low_digit_done:

    /* Store the ASCII characters in the message template */
    adr     x24, msg           /* Get address of the message template */
    strb    w20, [x24, #6]      /* Store high nibble at position after "Loop: " */
    strb    w21, [x24, #7]      /* Store low nibble */

    /* Print message */
    mov     x1, x24             /* Set message address for print */
    mov     x2, len             /* Set message length */
    mov     x0, 1               /* file descriptor: 1 is stdout */
    mov     x8, 64              /* write is syscall #64 */
    svc     0                   /* invoke syscall */

    add     x19, x19, 1         /* increment the loop counter */
    cmp     x19, max            /* see if we've hit the max */
    b.ne    loop                /* if not, then continue the loop */

    mov     x0, 0               /* set exit status to 0 */
    mov     x8, 93              /* exit is syscall #93 */
    svc     0                   /* invoke syscall */

.data
msg:   .ascii      "Loop: ##\n"   /* Message format for hexadecimal output */
len=   . - msg

[kzaw@aarch64-002 aarch64]$ ./hello
Loop: 00
Loop: 01
Loop: 02
Loop: 03
Loop: 04
Loop: 05
Loop: 06
Loop: 07
Loop: 08
Loop: 09
Loop: 0A
Loop: 0B
Loop: 0C
Loop: 0D
Loop: 0E
Loop: 0F
Loop: 10
Loop: 11
Loop: 12
Loop: 13
Loop: 14
Loop: 15
Loop: 16
Loop: 17
Loop: 18
Loop: 19
Loop: 1A
Loop: 1B
Loop: 1C
Loop: 1D
Loop: 1E
Loop: 1F
Loop: 20
