Niftyzk tutorials 3 – Edwards-curve Digital Signatures

Setting up your current directory
? What project do you want to scaffold? EdDSA signature verification
? Choose the hashing algorithm to use:  mimc7
? Do you wish to add public inputs to sign? (E.g: address,amount) yes
? Enter the name of the public inputs in a comma separated list (no numbers or special characters):  address,amount
Generating circuits
Generating javascript
Done

pragma circom 2.0.0;

include "../node_modules/circomlib/circuits/eddsamimc.circom";
include "../node_modules/circomlib/circuits/mimc.circom";

template VerifySignature(){
    signal input message;
    signal input address;
    signal input amount;

    signal input k;

    signal input Ax;
    signal input Ay;
    signal input S;
    signal input R8x;
    signal input R8y;

    component eddsa = EdDSAMiMCVerifier();

    component mimc7Hash = MultiMiMC7(3, 91);
    mimc7Hash.k <== k;
    mimc7Hash.in[0] <== message;
    mimc7Hash.in[1] <== address;
    mimc7Hash.in[2] <== amount;


    eddsa.enabled <== 1;
    eddsa.Ax <== Ax;
    eddsa.Ay <== Ay;
    eddsa.S <== S;
    eddsa.R8x <== R8x;
    eddsa.R8y <== R8y;
    eddsa.M <== mimc7Hash.out;

    }

component main {public [message,address,amount]}  = VerifySignature();

/**
 * The signature parameters used for verifying pedersen hash signed EdDSA
 * @typedef {Object} Account
 * @property {Buffer} prvKey - Private key buffer
 * @property {Uint8Array[]} pubKey - Public key is a tuple of 32 bit Uint8Array
 */

/**
 * @param {any} eddsa - The EdDSA object
 * @returns {Account}
 * Generate a new account which composes of a private and public key
*/
export function generateAccount(eddsa) {
    const prvKey = rbytes();
    const pubKey = eddsa.prv2pub(prvKey);
    return {
        prvKey,
        pubKey
    }
}

/**
 *
 * @param {Array} pubKey - Used for computing an address
 * @param {bigin | number} key -The key used for the mimc7 hash
 * @returns
 */

export async function getAddressFromPubkey(pubKey, key) {
    return mimc7(pubKey, key);
}

/**
 * @typedef {Object} Message
 * @property {string | bigint} message
 * @property {string | bigint} address
 * @property {string | bigint} amount
 */

/**
 *
 * @param {Message} data - The data content of the message. The hash of the data object will be signed
 * @param key {number | bigint} - The key used for the mimc7 hash
 * @returns {bigint} Returns a mimc7 hash
 */
export async function computeMessageHash(data, key) {
    return await mimc7(
        [
            BigInt(data.message),
            BigInt(data.address),
            BigInt(data.amount)
        ], key)
}

/**
 * @param {any} eddsa - the built EDDSA
 * @param {bigint} messagehash - The poseidon hash of the message
 * @param {Buffer} prvKey - The private key used to sign the message
 * @returns {Signature} signature
 */
export function signMessage(eddsa, messageHash, prvKey) {
    const signature = eddsa.signMiMC(prvKey, eddsa.F.e(messageHash));
    const pubKey = eddsa.prv2pub(prvKey);
    assert(eddsa.verifyMiMC(eddsa.F.e(messageHash), signature, pubKey))

    return {
        signature,
        pubKey
    }
}

/**
 * @typedef {Object} Signature
 * @property {Uint8Array[]} R8
 * @property {bigint} S
 * /

/**
 * @typedef {Object} SignatureParameters
 * @property {bigint} Ax
 * @property {bigint} Ay
 * @property {bigint} R8x
 * @property {bigint} R8y
 * @property {bigint} S
 */

/**
 * @param {any} eddsa
 * @param {Uint8Array[]} pubKey - The public key of the account
 * @param {Signature} signature - The signature of the signed message
 * @returns {SignatureParameters} - The signature parameters are prepared parameters, ready to use for the circuit
 */
export function getSignatureParameters(eddsa, pubKey, signature) {
    return {
        Ax: eddsa.F.toObject(pubKey[0]),
        Ay: eddsa.F.toObject(pubKey[1]),
        R8x: eddsa.F.toObject(signature.R8[0]),
        R8y: eddsa.F.toObject(signature.R8[1]),
        S: signature.S
    }
}

/**
 * This is a test input, generated for the starting circuit.
 * If you update the inputs, you need to update this function to match it.
 */
export async function getInput(){

    await buildHashImplementation()
    const eddsa = await getEDDSA();

    const account = generateAccount(eddsa);
    const key = 313; // just an example key for tests
    const message = rbigint();
    const address = rbigint()
    const amount = rbigint()
    const messageHash = await computeMessageHash({message,address,amount}, key)

    const signedMessage = signMessage(eddsa, messageHash, account.prvKey);

    const signatureParameters = getSignatureParameters(eddsa, account.pubKey, signedMessage.signature)

    return {
        Ax: signatureParameters.Ax,
        Ay: signatureParameters.Ay,
        S: signatureParameters.S,
        R8x: signatureParameters.R8x,
        R8y: signatureParameters.R8y,

        k: key,
        address,
        amount,
        message
    }
}

Setting up your current directory
? What project do you want to scaffold? EdDSA signature verification with Fixed Merkle Tree
? Choose the hashing algorithm to use:  poseidon
? Do you wish to add public inputs to sign? (E.g: address,amount) no

pragma circom 2.0.0;

include "../node_modules/circomlib/circuits/eddsaposeidon.circom";
include "../node_modules/circomlib/circuits/poseidon.circom";
include "./merkletree.circom";


template VerifySignature(levels){

    signal input message;
    signal input root;

    signal input pathIndices[levels];
    signal input pathElements[levels];


    //The parameters for the signature
    //The Ax and Ay parameters are the public key, Ax = pubKey[0], Ay = pubKey[1]
    signal input Ax;
    signal input Ay;
    signal input S;
    signal input R8x;
    signal input R8y;
    component eddsa = EdDSAPoseidonVerifier();

    component poseidon = Poseidon(1);
    poseidon.inputs[0] <== message;

    // Verify the signature on the message hash

    eddsa.enabled <== 1;
    eddsa.Ax <== Ax;
    eddsa.Ay <== Ay;
    eddsa.S <== S;
    eddsa.R8x <== R8x;
    eddsa.R8y <== R8y;
    eddsa.M <== poseidon.out;

    //We compute a public key by hashing Ax and Ay,
   // this will be later used with the merkle tree
   component pubKeyHasher = Poseidon(2);
   pubKeyHasher.inputs[0] <== Ax;
   pubKeyHasher.inputs[1] <== Ay;

   //Verify the merkle tree
   component tree = MerkleTreeChecker(levels);


  for (var i = 0; i < levels; i++) {
      tree.pathElements[i] <== pathElements[i];
      tree.pathIndices[i] <== pathIndices[i];
  }
  tree.root <== root;
  tree.leaf <== pubKeyHasher.out;
    }

component main {public [message,root]}  = VerifySignature(20);

CREATING A NEW MERKLE TREE

Enter how many accounts would you like to generate:
4
Generating accounts and addresses. Please wait!
Done
Generating merkle tree from addresses!
Done.Root is 21804813178957116268623645093306988559564490743632413729059072914509024611553
Serializing data.
Writing to file.
Done
